Elicent AXC 100 TP Centrifugal Inline Fan
Original price was: $249.00.$209.00Current price is: $209.00.
Pre-Order Product: ETA Early June
Capacity: 211 m3/hr (58.61 L/s)
Motor Type: Centrifugal
Ductable: Yes (100mm duct diameter)
View full technical specs further down the page
The Elicent AXC TP Centrifugal 100mm Inline Fan (Part number: 2AX5001) is a powerful solution designed to efficiently move air through ducts. With a maximum capacity of 211 m3/hr, this fan is suitable for medium-sized spaces. Its IPX2 protection ensures water/moist resistance, while its V2 technopolymer frame guarantees durability while also being lightweight. Installation is made easy with the integrated mounting bracket, making it an ideal choice for various domestic and commercial environments.
The Elicent AXC TP Centrifugal Inline Fan offers high-performance ventilation solutions suitable for a diverse array of environments. Engineered with durability and functionality in mind, the range features:
- Suitable for medium-sized rooms
- Lightweight and silent operating (32dB (A) max)
- Made in self-estinguishing V2 technopolymer
- Max temperature of extracted air: 50°C
- Backward curved blades and ball-bearing motor provided with thermal cut-out
- IPX2 rated
- Comply with ErP Directive 2009/125/CE and EU Regulation 1253/2014
| Manufacturer | Elicent |
|---|---|
| Model Number | 2AX5001 |
| Material | Plastic |
| Capacity (m3/hr) | 211 m3/hr |
| Capacity (L/S) | 58.61 L/s |
| Motor RPM | 2420 |
| Motor Type | Centrifugal |
| Recommended Room Size (Based on Achieving 15 air changes per hour) | 14.1 m3 |
| Noise Level | 32 dB(A) |
| IP Rating | IPX2 |
| Voltage | 220 – 240 |
| Installation | This fan requires hardwiring by an electrician |
| Duct Size | 100mm |
| Max Temperature of Transferred Air | 50 °C |
| Warranty | Elicent – The manufacturer offers a 2 year replacement warranty (conditions apply) |
| Capacity Disclaimer | All capacity figures and technical data quoted is provided by the manufacturer, Capacity figures are based on the unit freeflowing (not connected to ducting). If you are ducting this unit it is advisable to keep the duct run as short, straight and tight as possible |
| Room Size Recommendation Disclaimer | As stated our "Recommended room size" figures are based on achieving 15 air changes per hour. Generally we have found this to be suitable, however it does not constitute specific advice. |
