Elicent AXC Metal Centrifugal Inline Exhaust Fan

Elicent AXC Metal Centrifugal Inline Exhaust Fan1

Elicent AXC 100 B Centrifugal Inline Fan

Name: Elicent AXC 100 B Centrifugal Inline Fan
SKU: EXELAXCM100B
Availability: InStock

IN STOCK | Typically dispatches within 3 business days

$269.00

SKU: EXELAXCM100B Categories: Centrifugal Fans, Elicent, Elicent Centrifugal Inline Fans, Exhaust Fans from Brand Manufacturers, In Line Fans, Inline Exhaust Fans

Capacity: 260 m3/hr (72.22 l/s)
Motor Type: Centrifugal
Ductable: Yes (100mm duct diameter)
View full technical specs further down the page

The Elicent AXC 100 B Centrifugal Inline Fan offers exceptional ventilation with a powerful 260 m3/hr airflow. Compact yet efficient, it’s perfect for medium-sized spaces. Built for durability, it delivers quiet operation and hassle-free maintenance for long-lasting performance. The integrated mounting bracket facilitates quick and easy installation.

The Elicent AXC 100 B Centrifugal Inline Fan presents a range of features tailored to meet diverse ventilation needs across residential and commercial settings

High-performance centrifugal fans for in-line duct installation
Easy and cost-effective solution for a centralised ventilation requirement
Silent operating only at 36 dB(A)
Max temperature of extracted air: 60°C
Ball-bearing motor protected, backward-curved blades
Steel frame with epoxy finish inside and outside
Product IPX4 protected

Disclaimer: The manufacturer has provided a sound power level of 55.8 dB(A) for this product, measured in accordance with ISO 3746:2010. This measurement is the Lw, which is designed to measure the total acoustic energy – think of it as the ‘wattage’ of sound. In contrast, the lower decibel level quoted reflects the sound pressure level at 3 metres, offering a more practical indication of the noise experienced during operation.

Manufacturer	Elicent
Model Number	2AX1123
Material	Metal
Capacity (m3/hr)	260 m3/hr
Capacity (L/S)	72.22 L/S
Motor RPM	2600
Motor Type	Centrifugal
Recommended Room Size (Based on Achieving 15 air changes per hour)	17.3 m3
Noise Level	36 dB(A)
IP Rating	IPX4
Voltage	220 – 240
Installation	This fan requires hardwiring by an electrician
Duct Size	100mm
Max Temperature of Transferred Air	60 °C
Warranty	Elicent – The manufacturer offers a 2 year replacement warranty (conditions apply)
Capacity Disclaimer	All capacity figures and technical data quoted is provided by the manufacturer, Capacity figures are based on the unit freeflowing (not connected to ducting). If you are ducting this unit it is advisable to keep the duct run as short, straight and tight as possible
Room Size Recommendation Disclaimer	As stated our "Recommended room size" figures are based on achieving 15 air changes per hour. Generally we have found this to be suitable, however it does not constitute specific advice.
