Oerre Turbo Centrifugal Inline Fan 200mm
IN STOCK | Typically dispatches within 1-2 business days
$429.00
Capacity: 1050 m3/hr (291.67 l/s)
Motor Type: Centrifugal
Ductable: Yes (200mm duct diameter)
View full technical specs further down the page
Elevate your ventilation system with the Oerre Turbo Centrifugal 200mm Inline Fan, boasting an impressive capacity of 1,050m³/hr. Designed for large-scale applications, this fan is ideal for environments requiring high-volume air transfer, such as large factories and expansive commercial spaces. With its robust construction and IPX4 protection, this fan ensures long-term reliability and performance. The integrated mounting bracket facilitates quick and hassle-free installation, while its sleek design complements any industrial or commercial setting.
Add a Run on timer
This fan can be used with the following run on timer. An electrician will be required to install a 4 pin plug outlet. This timmer allows for the run on period to be adjusted from 0-60 minutes.
The Oerre Turbo Centrifugal range offers high-performance ventilation solutions suitable for a diverse array of environments. Engineered with durability and functionality in mind, the range features:
- Suitable for domestic, commercial, and industrial environments.
- Max temperature of extracted air: 40°C.
- Ball bearing motor protected.
- Zinc plated steel frame, high resistance motor support
- Electrical box IP54 protected.
- Product IPX4 protected.
- Double insulated product, without ground wire for fast connection.
Whether you’re outfitting a small office or a large warehouse, the Oerre Turbo Centrifugal range delivers exceptional ventilation performance you can rely on.
| Manufacturer | Oerre |
|---|---|
| Model Number | UF38100 |
| Material | Metal |
| Capacity (m3/hr) | 1050 m3/hr |
| Capacity (L/S) | 291.67 l/s |
| Motor RPM | 2550 |
| Motor Type | Centrifugal |
| Recommended Room Size (Based on Achieving 15 air changes per hour) | 70 m3 |
| Noise Level | 58 dB(A) |
| IP Rating | IPX4 |
| Voltage | 220 – 240 |
| Installation Statement | This fan requires hardwiring by an electrician |
| Duct Size | 200mm |
| Max Temperature of Transferred Air | 40°C |
| Warranty | Oerre: The manufacturer offers a 1 year replacement warranty. Conditions Apply. Contact your store of purchase for warranty issues. |
| Capacity Disclaimer | All capacity figures and technical data quoted is provided by the manufacturer, Capacity figures are based on the unit freeflowing (not connected to ducting). If you are ducting this unit it is advisable to keep the duct run as short, straight and tight as possible |
| Room Size Recommendation Disclaimer | As stated our "Recommended room size" figures are based on achieving 15 air changes per hour. Generally we have found this to be suitable, however it does not constitute specific advice. |
| Current | 0.47 |
| Barcode Number | 8009278220839 |
